Immediate Delivery
| Specification | Details |
|---|---|
| Price | 64,000/- |
| Vessel Size | 13*54 |
| MPV Size and Mounting | 25NB Top |
| Pebbles | 25 Kgs |
| Iron Removal Media | 50 Ltrs |
| Maximum Flow (*1000 Ltrs/Hr) | 3 |
| MPV Type | Manual |
| Max Operating Pressure | 3.5 BAR |
| Specification | Details |
|---|---|
| Price | 64,000/- |
| Vessel Size | 13*54 |
| MPV Size and Mounting | 25NB Top |
| Pebbles | 25 Kgs |
| Iron Removal Media | 50 Ltrs |
| Maximum Flow (*1000 Ltrs/Hr) | 3 |
| MPV Type | Manual |
| Max Operating Pressure | 3.5 BAR |
| Specification | Details |
|---|---|
| Price | 89,000/- |
| Vessel Size | 16*65 |
| MPV Size and Mounting | 40NB Side |
| Pebbles | 25 Kgs |
| Iron Removal Media | 75 Ltrs |
| Maximum Flow (*1000 Ltrs/Hr) | 6 |
| MPV Type | Manual |
| Max Operating Pressure | 3.5 BAR |
| Specification | Details |
|---|---|
| Price | 88,000/- |
| Vessel Size | 13*54 |
| MPV Size and Mounting | 25NB Top |
| Pebbles | 25 Kgs |
| Iron Removal Media | 50 Ltrs |
| Maximum Flow (*1000 Ltrs/Hr) | 3 |
| MPV Type | Automatic |
| Max Operating Pressure | 3.5 BAR |
| Specification | Details |
|---|---|
| Price | 88,000/- |
| Vessel Size | 13*54 |
| MPV Size and Mounting | 25NB Top |
| Pebbles | 25 Kgs |
| Iron Removal Media | 50 Ltrs |
| Maximum Flow (*1000 Ltrs/Hr) | 3 |
| MPV Type | Automatic |
| Max Operating Pressure | 3.5 BAR |
| Specification | Details |
|---|---|
| Price | 1,24,000/- |
| Vessel Size | 14*65 |
| MPV Size and Mounting | 40NB Top |
| Pebbles | 25 Kgs |
| Iron Removal Media | 75 Ltrs |
| Maximum Flow (*1000 Ltrs/Hr) | 6 |
| MPV Type | Automatic |
| Max Operating Pressure | 3.5 BAR |
Iron filters are used to remove excess iron from household water supplies, preventing staining of fixtures, laundry, and appliances. This helps maintain the aesthetic quality of water and prolongs the life of plumbing systems and appliances.
In industrial settings, iron filters are crucial for treating water used in manufacturing processes. They help protect equipment from iron-related damage and ensure the water used in production is clean and meets quality standards.
For agricultural applications, iron filters remove iron from irrigation water, preventing damage to irrigation systems and improving water quality for crops.
Iron filters are essential for maintaining high water quality by effectively removing excess iron and other contaminants from water. High levels of iron can cause staining on plumbing fixtures, laundry, and appliances, and can lead to unpleasant tastes and odors. By filtering out these impurities, iron filters help prevent damage to plumbing systems and extend the lifespan of household and industrial equipment. Additionally, they improve the aesthetic and sensory qualities of water, ensuring it is clean, clear, and suitable for various uses. Iron filters are crucial in residential, industrial, and municipal settings for safeguarding water quality and maintaining overall system efficiency.
1.Pre-Treatment: Water may undergo pre-treatment to adjust its pH or oxidize dissolved iron, making it easier to filter out. In some systems, chemicals like chlorine or potassium permanganate are added to convert dissolved iron into a solid form.
2.Filtration: Water flows through a filter media, which could include materials such as sand, manganese greensand, or specialized iron removal media. The filter media traps and removes the solid iron particles from the water.
3.Backwashing: To maintain the effectiveness of the filter, it periodically undergoes a backwashing process. During backwashing, water is reversed through the filter to flush out accumulated iron and other contaminants, cleaning the filter media and restoring its filtering capacity.
4.Post-Treatment: In some systems, additional post-treatment steps are used to ensure the water meets quality standards, including further filtration or disinfection.
